Purchasing Vacuum Precooling Machine for Vegetable and Fruit

Purchasing Vacuum Precooling Machine for Vegetable and Fruit

1.Vacuum Cooler is the quickest and most cost-effective cooling system for vegetable, fruits, flowers & more.

2.Vacuum cooler, which can strongly improve your product quality and at the same time reduce your cooling costs, is now becoming an acceptable investment for almost all vegetable growers!

3.Vacuum Cooler cools fresh product quickly and uniformly in large loads within 15-30mins/cycle, also suitable for packed produces.

ICEUPS will design and offer the most suitable machine to clients'requirements：
* Vacuum Cooler Machine Condenser System Type：
1) Air condenser:The simplest construction, suitable for small system.Easy to integrate.
2) Water condenser: Low cost, efficient and easy to install. Perfect for most districts climates.
3)Evaporative condenser: Optional system for dry climates, or if water availability is limited.

*Door type of Vacuum Cooler Machine

1) Standard swing door: The simplest construction, manual operation. The ramp for this system is relatively long, and is mounted inside the cooling chamber.
2)Horizontal sliding door: This eletrical driven door is optimal if the cooling skid is placed ,besides the vaccum chamber (one pallet modle and more than 6 pallets systems).
3)Upward lift door:Suggested solution for all systems from 2-6 pallets. Easy installation , easy ramp construction.

Technical parameter of Vacuum Cooler:
ICEUPS standard range consists of models:1pallet up to 10 pallets, and produce weight ranging from 300 to 5,000 kg. The number of pallets defines the chamber dimensions, and the number of vacuum pumps needed to create the vacuum.

MODELS and SPECIFICATION OF VACUUM COOLER for Vegetable/Fruits/Flowers
Model No. /Processing Capacity/ Inside Dimension of Chamber(mm)/ Cooling capacity /Power Supply/ Total Power
1.KMS-01P ,1 pallet/300~500kg ,Chamber 1400x1400x2200, 60kw ,220~600v/3P, 31.2kw
2.KMS-02P,2pallets/700~1000kg ,Chamber 2600x1400x2200, 88.5kw ,220~600v/3P, 47.4kw
3.KMS-03P, 3pallets/1100~1500kg, Chamber 3900x1400x2200 ,113kw, 220~600v/3P, 58.7kw
4.KMS-04P, 4pallets/1500~2000kg ,chamber 5200x1400x2200, 163kw ,220~600v/3P, 82.7kw
5.KMS-06P, 6pallets/2200~3000kg,chamber 6500x1400x2200, 206kw, 220~600v/3P, 104kw
6.KMS-08P, 8pallets/3000~4000kg,chamber 5300x2600x2200 ,293kw ,220~600v/3P, 137kw
7.KMS-10P, 2Aircraft pallets/4000~5000kg,chamber 6600x2600x2200 ,478kw ,220~600v/3P, 249.5kw

Main Features of 1P Vacuum cooler

1)Green Cooling: Energy saving &Optimal cooling efficiency
2)Radily Cooling: From 30°C to 2°C in 20-30 Minutes
3)Extend Shelf Life: Stay freshness and Nutrition Longer
4)Accurated Control: PLC combine with sensitive sensors&valves
5)Easy Operation Design: Automatic Control work with touch screen
6)Reliable Parts: Busch/Leybold/Elmo Rietschle/Bitzer/Danfoss/Johnson/Schneider/LS

Machine Parts

Name: Vacuum Pump

Brand: Leybold

Original: Germany

 Global famous vacuum pump with good quality

other brand : TongXin, Rietschle ,Busch

Main Features

Name: Vacuum Chamber
Brand: ICEUPS(Kemeisi）
Original: China

1) the size of the chamber is defined by the amount of pallets(1~12pallets,weight ranging from 250 to 4,000kg)

2)Crops are to cool within 20~30minutes per time, and their individual

3)Chamber Material：Painted mild steel and Stainless steel

Machine Parts

Name: Compressor
Brand: Bitzer
Original: Germany
Global famous compressor
You can choose HANBELL,GEA BOCK

Main Features

Name: Intelligent control system
Brand: LS
Original: Korea
Automatic and good quality, strong driving force, low fuel consumption, high economic benefits.

Automatical PLC programmable control system
