Battery powered roof top 12v 24v van refrigeration units

FOB Price:

US 1,000-1,500 / Unit

Min.Order Quantity:

1 Unit/Units

Supply Ability:

500 Unit/Units per Month

Port:

Qingdao , China

Place of Origin:

Henan, China (Mainland)

Payment Terms:

L/C,T/T,Western Union

Brand:

Recool

Products Model:

DT280

Products Details
Company Profile

Quick Details

Brand Name: Recool

Model Number: DT280

Place of Origin: Henan, China (Mainland)
Temperature range in box body: -15℃ ~ +25℃
cooling capacity: - 5℃/1100W, -15℃/700W,
voltage: dc 12V/ 24V/ 48V/ 60V /72V
suggested box body volume: 2m3~ 5 m3
refrigerant: R404a
size for evaporator: 600mm *530mm * 150mm
size for condenser: 865mm *700mm * 185mm
weight for evaporator: 8kgs
weight for condenser: 30kgs
product name: van refrigeration units

Packaging & Delivery

Packaging Details: carton packing for van refrigeration units
Delivery Detail: Shipped in 5 working days for van refrigeration

Specifications

Battery powered roof top 12v 24v van refrigeration units

Product Description

This DT280 van refrigeration units is designed for refrigerated van insulated

for fresh or frozen produce transport. DT280 is drvien by vehicle's battery .

The box body is at 2m³ (-15℃) or 5m³(-5℃).

Reliable performance

Digital display control

ISO9001 certificated

comptitive price

Technical data
Model	DT280
Temperature range in box body	-15℃ ~ +25℃
Drive	electric
Construction	split
Installation	roof top
Voltage	DC12V/24V/48V/60V/72V/321V, etc
Current draw	12V/90A, 24V/48A
Suggested box body volume	2m³ ~5m³
Control	digital microprocesser in cab
Compressor	electric , 18cc/r
Refrigerant	R134a
Gas charge	0.8kgs ~ 1kgs
Protection	High & low pressure switch
Condenser coil	copper tube aluminum fin
Evaporator coil	copper tube aluminum fin
Size for evaporator	600mm530mm150mm
Size for condenser	865mm700mm185mm
Weight for evaporator	8kgs
Weight for condenser	30kgs
Application	refrigerated van

Cooling Capacity

℃	℉	Watts	Kcal/h	Btu/h
-5	23	1100	946	3753
-15	5	700	602	2388
As amebient temperature is +30℃
